| Model | The largest length(mm) | Max Screw Diameter(mm) | The main slide stroke | Main Motor (KW，Poles) |
The oil pump （KW） | Productivity(Pcs/Min) | Weight(Ton) | Packing size L× W×H |
| （mm） | （m） | |||||||
| M4-40C/B | 40 | Φ4 | 62 | 1.5, 4 | 0.37 | 120-150 | 0.97 | 1.6x1x1.2 |
| M4-40D | 40 | Φ4.5 | 70 | 1.5, 4 | 0.37 | 150-200 | 1.4 | 1.6x1x1.3 |
| M5-120C/B | 120 | Φ6 | 160 | 3, 6 | 0.37 | 50-70 | 2.3 | 2.8x1.3x1.3 |
| M6-60C/B | 60 | Φ8 | 92 | 4, 6 | 0.37 | 80-110 | 2.7 | 2.3x1.35x1.4 |
| M6-100C/B | 100 | Φ8 | 130 | 4, 6 | 0.37 | 60-90 | 2.7 | 2.4x1.35x1.4 |
